Need reel schematics

[hhapibeli]

I am returning to fishing in my retirement after 30+ years of nonfishing. I have a Shakespeare 2155 that I want to refurbish, though it seems to be in good shape.
Does anyone know where I can get a schematic for this reel? Also, what is a good book for reel and rod care and maintenance?
I will be fishing the salt chuck around my Southern Gulf Islands home, by boat and from the shore.
Thanks all.



[Hardy Guy]

Shakespeare 2155

I could not find anything on a quick search. You may need to just use a schematic for a similar reel and go from there. Or just go for it and take your time and take pictures on the way. There are some You tube vids for service. Most reels of the same type are generally similar to how they operate.



[hhapibeli]

thanks hardy Guy. Wilco.



[CIVANO]

I do not know what joining Orca means but they say they have diagram for the 2155. UK site

Sorry for the inconvenience... - ORCA

We’re sorry but access Members Only pages including our 1,700+ volume library requires login by a full ORCA member. Do you want unlimited free access to our library (for personal use only)? Join ORCA today! If you are already a member, please login to access the library. Login to ORCAonline...

www.orcaonline.org



[hhapibeli]

Thank you. I found some schematics.
